Technical parameters:
|
Type |
CJX2-F400 |
CJX2-F500 |
CJX2-F630 |
CJX2-F780 |
CJX2-F800 |
|
|
Rated Current |
Ie max AC-3(Ue≤440V) |
400A |
500A |
630A |
780A |
800A |
|
Ie max AC-1(θ≤40℃) |
500A |
700A |
1000A |
1600A |
1000A |
|
|
Main Contacts(NO) |
2、3、4 |
2、3、4 |
2、3、4 |
2、3、4 |
3 |
|
|
Rated Insulated Voltage(Ui) |
1000V |
1000V |
1000V |
1000V |
1000V |
|
|
Rated Impulse Withstand Voltage |
8kV |
8kV |
8kV |
8kV |
8kV |
|
|
Rated Operational Voltage (Ue)max |
1000V |
1000V |
1000V |
1000V |
1000V |
|
|
Standards-compliant |
IEC60947-4-1, GB14048.4, EN60947-4-1 |
|||||
|
Conventional Thermal Current Ith(θ≤40℃) |
500A |
700A |
1000A |
1600A |
1000A |
|
|
Operation Frequency(times/h) |
AC-1，AC-2，AC-3 |
600 |
600 |
600 |
600 |
600 |
|
AC-4 |
300 |
300 |
300 |
300 |
300 |
|
|
Rated Power(AC-3) |
220/240V |
110kW |
147kW |
200kW |
220kW |
220kW |
|
380/400V |
200kW |
250kW |
335kW |
400kW |
400kW |
|
|
415V |
220kW |
280kW |
375kW |
425kW |
425kW |
|
|
440V |
250kW |
295kW |
400kW |
425kW |
425kW |
|
|
500V |
257kW |
355kW |
400kW |
450kW |
450kW |
|
|
660/690V |
280kW |
335kW |
450kW |
475kW |
475kW |
|
|
1000V |
185kW |
335kW |
450kW |
450kW |
450kW |
|
|
Connection/Wiring
Operation Voltage (θ≤55℃) |
Number of Lines Line Size(mm2) |
2 30×5 |
2 40×5 |
2 60×5 |
2 100×5 |
2 60×5 |
|
Cable with Splicing(mm2) |
2×150 |
2×240 |
- |
- |
- |
|
|
Cable with Connector(mm2) |
- |
- |
- |
- |
- |
|
|
Screw Diameter |
Φ10 |
Φ10 |
Φ12 |
Φ12 |
Φ12 |
|
|
Tightening Torque(N.m) |
35 |
35 |
58 |
58 |
58 |
|
|
Equipped With Fuse Protector (SCPD) |
Type |
RT16-3 800A |
RT16-3 1000A |
RT16-3 1250A |
RT16-3 1600A |
RT16-3 2500A |
Dimensions(mm) :
CJX2-F600/6004/800
|
CJX2F |
a |
P |
Q |
Q1 |
S |
Φ |
f |
b |
b1 |
M |
N |
C |
L |
G |
H |
Φ1 |
Z |
Y |
X1 |
|
|
500V≤ |
>500V |
|||||||||||||||||||
|
630 |
309 |
80 |
60 |
89 |
40 |
M12 |
201 |
304 |
280 |
264 |
202 |
255 |
155 |
180(100-195) |
185 |
10.5 |
60.5 |
68.5 |
20 |
25 |
|
6304 |
309 |
80 |
60 |
89 |
40 |
M12 |
201 |
304 |
280 |
264 |
202 |
255 |
155 |
240(150-275) |
185 |
10.5 |
60.5 |
68.5 |
20 |
25 |
|
800 |
309 |
80 |
60 |
89 |
40 |
M12 |
201 |
304 |
280 |
264 |
202 |
255 |
155 |
180(100-195) |
185 |
10.5 |
60.5 |
68.5 |
20 |
25 |
